A Beautiful System that Converts Existing Windows into Double Glazing
Retrofit double glazing is a brilliant option for people who want to upgrade to double glazing without replacing their perfectly good windows. ecoGlaze® is a revolutionary secondary glazing system that can be easily applied to your existing windows, and the good news is they’ll still open and close as they did before.
Did you know that glass is an excellent conductor of heat? In summer, an unshaded window will allow heat from outside to transfer into your home, compromising your comfort as you try to keep cool. In the winter, your expensive heating is being lost to the outside, while your heater’s energy consumption delivers unnecessarily high energy bills.
What is ecoGlaze® Secondary Glazing?
Secondary glazing is the addition of a highest-quality acrylic layer to your existing window sash, it provides optimal still air space for optimal performance.
ecoMaster‘s own secondary glazing system, ecoGlaze® offers all of the benefits of double glazing at about 1/3 of the cost of high-quality double glazing. Best of all, your windows and doors continue to operate as they did before and the elegant design blends in perfectly with your existing window frames.
There are three models available: fixed, in-sash and on-sash. These options cater for awning windows, double hung (sash) windows, sliding applications and fixed panes of glazing.
Secondary Glazing vs. Double Glazing…
|1.||ecoGlaze® is more cost effective than replacement double glazing in terms of both materials and installation costs, while achieving the same level of efficiency.|
|2.||ecoGlaze® is far less invasive than having your existing windows replaced which requires the architraves and walls to be ‘made good’ and repainted following installation.|
|3.||ecoGlaze® is more resource efficient, allowing all of the benefits of double glazing without the need to dispose of your existing windows.|
|4.||ecoGlaze® is non-intrusive, allowing sliding and awning windows to continue to operate as normal. The appearance, character and function of the window or door is not compromised.|
How does secondary glazing work?
A highest-quality acrylic panel is fitted to the window sash, held in place by a timber moulding and a spacer. These mouldings are fitted with magnets which lock the acrylic layer firmly in place. Mouldings can be painted in a standard or custom colour, or can be stained and varnished to match your existing frames. The entire system can be easily removed, though this is rarely necessary as dust cannot enter between the acrylic and the glazing.
The ecoMaster team is highly professional and unusually efficient, and their product has made a tangible difference to the comfort of our house. We are very happy to recommend them to others.
PM, North Fitzroy, 2011
The benefits of secondary glazing…
|✓||Secondary glazing adds real value to your home|
|✓||ecoGlaze® has been tested by the WERS Testing Laboratory (Windows Energy Rating Scheme)|
|✓||Looks and functions like factory fitted double glazing, visually integrating with your window rather than looking like an add-on|
|✓||Glass-like acrylic panels are virtually unbreakable and come with a 30 year warranty|
|✓||High quality solution that last the lifetime of your home|
|✓||Does not inhibit the operation of your doors and windows|
|✓||Amazingly affordable at about 1/3 of the cost of high quality double glazing|
|✓||Reduces your heating and cooling energy consumption|
|✓||Improves the comfort of your home|
|✓||An environmentally sustainable solution, reducing landfill|
|✓||Your ecoGlaze® product and its installation is guaranteed for 7 years, click here to learn more.|
A reasonable indication is around $380 per square metre, depending upon the type and size of your windows, and your location. However, some types of glazing, such as double hung windows, can cost more.
Refer to our Easy-to-Measure Guide to send through the details of your windows for a retrofit double glazing estimate.
ecoGlaze® Retrofit Double Glazing works by trapping a layer of still-air between your existing windows and the ecoGlaze® acrylic panel. This layer of air greatly reduces the heat transfer through your glass window. The acrylic panel is secured in place by beautifully made timber mouldings held firmly to the window frame with invisible magnets.
Generally speaking, the ecoGlaze® Retrofit Double Glazing System can be easily applied to all timber windows and some aluminium windows. This is dependent on the window frame having enough room for the ecoGlaze® system and sufficient insulating air pocket. Some residential aluminium-framed windows do not allow enough space for the ecoGlaze® system to fit. However, many homes (particularly apartments) are fitted with commercial aluminium window frames, which are often the perfect size.
Refer to our Easy-to-Measure Guide to check whether your windows are suitable for ecoGlaze®.
ecoGlaze® is a suitable treatment for timber framed glazing, doors included. It can be applied to French doors; sliding doors; hinged doors; doors with colonial bars; or doors with lead lighting.
No, the ecoGlaze® Retrofit Double Glazing System does not alter the operation of your windows or doors. You will be able to open them normally.
The largest ecoGlaze® panel that can be safely installed is 3000mm x 2000mm.
ecoGlaze® is a truly elegant product designed to satisfy even the most discerning home owners. Its sleek timber frame blends with your existing joinery to provide a seamless solution. The optical grade acrylic panel is crystal clear, to preserve your view.
This is one of the most impressive features of ecoGlaze®.
The ecoGlaze® Retrofit Double Glazing System is supplied in either raw timber (Tasmanian Oak) or painted in Dulux Natural White. The raw timber mouldings are ready to be stained and finished to match your existing window frames. You may choose to do this yourself or choose from ecoMaster’s 16 available stains and we can stain them for you. Custom paint colours can also be arranged for an additional fee.
ecoGlaze® is primarily a thermal product, that means it is designed to improve the comfort of your home in summer and winter. All forms of secondary glazing will reduce street noise to some extent, however, while it provides some acoustic benefit, its major focus is to vastly improve the thermal performance of the glazing in a way that is aesthetically beautiful.
Neither ecoGlaze® nor any other form of retrofit double glazing will totally eliminate external noise from your home and should not be viewed as a complete sound-proofing solution. Sound travels around building elements and so it can travel around an acoustically effective window or door.
Any noise abatement should be undertaken in a holistic manner and would usually include thorough draught proofing as well as treatments to the walls, floors and ceilings. Often in apartments the glazing is the major source of noise infiltration and, therefore ecoGlaze® would provide significant acoustic benefit.
After we have provided an estimate, we can arrange to have a member of our team visit and inspect your windows to provide a firm quote and show you how ecoGlaze® will look in your home.
Yes it certainly will. ecoGlaze® will reduce the heat loss by more than 50%, making a huge difference to the comfort of your home. This will significantly save you on your winter heating bill because you will need to use your heater much less.
Even traditional double glazing solutions cannot solve the problem of direct summer sun striking the glass.
Providing there is no direct sunlight striking your windows,the ecoGlaze® Retrofit Double Glazing System is highly effective in making sure that the summer heat stays outside. ecoGlaze® will reduce the heat transfer by up to 50%. However, if there is direct summer sun striking the glass, then external shading is the appropriate solution.
Brand new double glazed windows are much more expensive than secondary glazing. There is also a considerable amount of effort involved in selecting, arranging, installing, plaster repair, painting and cleaning up afterwards.
With replacement windows, the old heavy windows also need to be removed and properly disposed of. Tradesmen need to install the new windows carefully and the architraves and plaster around each window replaced or repaired. Finally the painters will need to repaint walls and / or architraves to match your existing paintwork. It can be challenging to co-ordinate multiple tradespeople in a timely manner when trying to get your home back to normal.
Also, we often we hear that people are disappointed to find that their brand new double glazing does not allow the adequate still air space to deliver the comfort they paid for.
Because ecoGlaze® is pre-prepared in our factory, installing ecoGlaze® in your home is a relatively simple process that takes approximately one hour per window. No other structural changes or co-ordinating tradespeople is required. Your home is left clean and tidy with seamless secondary glazing that provides perfect still air space.
There are a number of glazing companies that provide this service. Please be mindful that your original window frames were designed for a single pane of glass and are weighted to allow them to open and close normally. So there are two issues with replacing the glass:
- Adding an IGU to single glazed windows will make them very heavy. The additional weight is often too heavy to allow the windows to self-support in an open position. Doors that have been treated this way often experience strain on the hinges or tracks which can cause problems in the future.
- The smaller the gap between layers of glass, the less effective it will be. Because your original frames were designed for a single pane of glass, they were not constructed to accept wider glazing units. This forces the replacement glazing (IGU) to be very narrow, fitting two layers of glass into a space that was designed for one layer. This compromises it’s thermal effectiveness as the gap will allow conduction of heat and cold, which is exactly what you are trying to avoid.
ecoGlaze® has none of these problems because it weighs much less than glass, allows your windows to open and close normally. Its design provides the best possible still-air space to maximise thermal performance.
It is not necessary for the ecoGlaze® system to be sealed. ecoGlaze® creates a still-air space between the existing glass and the added acrylic panel. It is the still-air space that provides the insulative effect in ecoGlaze® and all other forms of secondary or double glazing.
ecoGlaze® does not contain Argon or any other chemical element. Argon filled double glazing is one of the most expensive types of double glazing available. It is important to note that Argon provides virtually no additional benefit unless it is combined with a ‘low e coating’, which requires the glass to be replaced.
Believe it or not, no glazing is vacuum sealed because it would put the two panes of glass under pressure and eventually the two panes would touch. Factory fitted double glazing is hermetically sealed, meaning that no air can enter or escape.
ecoGlaze® does not require a hermetic seal for it to be effective, it simply requires adequate still air space. ecoGlaze® has been designed to provide the best thermal performance by having a still air space of around 14mm.[/toggle]
There are a number of reasons why the ecoGlaze® Retrofit Double Glazing System has been designed using an acrylic panel instead of glass:
- Due to its flexibility acrylic is very difficult to break which makes it extremely safe. By comparison, glass is brittle, rigid and will shatter on impact.
- Acrylic is far less conductive than glass, which means that it will retain your winter warmth and protect you from summer heat transfer. In fact, acrylic conducts five times less than glass.
- Acrylic is light weight and easy to handle it can be safely added to your existing windows. As glass is a rigid, dangerous product, there are stringent safety requirements. It is not economically viable to be compliant with the Australian Glazing Standard if glass is used for this purpose.
The level of conduction of heat is measured by a number called a U-value. The U-value is measured by 1/R where R is the rate of heat resistance. The lower the U-Value, the better the performance of the glazing.
The U-value of a 3mm single glazed window with aluminium frame is 6.9. Compare this to a double glazed unit, with 6mm spacing and aluminium frames, with a U-value of 3.8. ecoGlaze® will be able to take a wooden framed single glazed window with a U-value of 5.5 down to a secondary glazed unit with a U-value of 3.0.
SHGC measures how well a product blocks heat caused by sunlight. The SHGC is the fraction of incident solar radiation admitted through a window, both directly transmitted, and absorbed and subsequently released inward. SHGC is expressed as a number between 0 and 1. The lower a window’s SHGC, the less solar heat it transmits. ecoGlaze carries a SHGC between 0.57 to 0.61.
ecoGlaze® uses the highest quality extruded acrylic panels for the glazing materials. This material is manufactured in Germany to a high degree of precision so that, optically, it is virtually indistinguishable from glass. It has a 30-year warranty against discolouration and crazing.
Secondary glazing (retrofit double glazing) works the same way as factory made double glazing by providing a layer of still air that improves the insulation value of otherwise highly conductive glass. In factory made units you have the opportunity to select many glass treatment options and also a gas fill. These units are hermetically sealed and have desiccant in them to absorb any water vapour that may impregnate the seals.
The ecoGlaze® Retrofit Double Glazing System is not sealed and does not include a desiccant. It relies on the water vapour in the air not being so high as to create condensation in the air space. This means that of all of the Melbourne-based installations we have carried out, there have been no reports of a moisture problem.
There have been two homes at altitude (above 500 metres), that have a minor problem with misting. The misting is insufficient to condense and it dissipates during the day.
The “Glazing in Buildings” Standard AS1288 concerns itself with two things: Wind Loading and Human Impact Safety.
- Wind Loading: Will the windows hold up against the winds expected in the setting in which they are being installed?One aspect of this is the thickness of the glass versus the area of the glass. The bigger the area the thicker the glass required. The higher the wind rating of the area the thicker the glass required.
- Human Impact Safety: If a person impacts the glass with speed or force, will it break and damage the windows or themselves?Again, this goes towards the thickness of the glass, particularly of low-to-the-ground glazing and in the case of wet areas, it is about using Grade A safety glass.The glazing standard has been significantly improved over the last few years, so many homes may not have compliant glazing. Adding ecoGlaze® will enhance the safety of your windows because the acrylic panel that is added internally is almost unbreakable. It won’t break due to impact from inside your home.
Due to the pre-production in our factory, installation is quick and tidy. Our installers are incredibly conscientious when working in your home and have a long-standing reputation for leaving every home clean and tidy. There is no damage to your windows or surrounds and no re-plastering or painting is necessary.
We recommend you allow approximately one hour per window pane. A whole home can be retrofitted with the ecoGlaze® Retrofit Double Glazing System within 1 to 2 days.
Whilst it is possible to remove the ecoGlaze® Retrofit Double Glazing System from your windows for cleaning, it is not usually required. However, if you wish to repaint your window frames, the timber mouldings held firmly to the window frame with invisible magnets make removing the acrylic panel a simple task.
The ecoGlaze® acrylic panel is strong and durable. Light scratches can be polished out with a soft cloth and Silvo. If the damage is severe, because the panel is separate from the timber moulding, it is a simple and relatively inexpensive process for our installers to cut and fit a new acrylic panel to replace the damaged panel.
If a child or pet impacts with a regular pane of glass, the results can be tragic. Fitting ecoGlaze® to the internal window will enhance the safety of your home because the acrylic panel that is added is almost unbreakable. It won’t break due to impact from inside your home, making your home much safer for even the most boisterous child or pet.
The ecoGlaze® Retrofit Double Glazing System is not suitable for sloping glass roofs or atriums. ecoMaster offers a quadruple glazed skylight diffuser to replace a single glazed skylight diffuser as an alternative. ecoMaster can also treat a skylight well at ceiling level to reduce the conditioned space of the home as well as eliminating draughts that come from a ventilated skylight.
